Hotchkis Chassis Max Handle Bar

Part#: 20101


  Hotchkis Chassis Max Handle Bar


We did your comparison shopping for you!
Buying from us here at Andy's means not only are you using our website to learn about and review your product choices, but you're choosing to let us take care of your order as well.  It will be our privelege to do so!  We take your business very seriously and will do our best to be extraordinarily helpful to you through the order fulfillment process.  Learn more about us by clicking here
Direct from Andy's
$557.00
BUY FROM ANDY'S
eBay
$5.53
BUY FROM EBAY
Why are we showing competitor prices? Click Here




PRODUCT DETAILS
Fits On:

67-69 Chevrolet Camaro, 68-74 Chevrolet Nova


Description:
Description:

Chassis Max Handle Bars from Hotchkis are a critical component for any high-performance 1967-1969 Camaro or 68-74 Nova. First generation F-bodies use a subframe that can flex during hard cornering, altering suspension geometry and even alignment. Hotchkis has solved this problem by applying nature's strongest shape: the triangle. Handle Bars tie the control arms to each other and the firewall with high-strength tubing, CNC bent brackets and laser cut gussets for maximum strength and rigidity. The result is incredible handling and driver control that makes the most of your high performance suspension.

Application Note: This current design may not fit some models equipped with LS motor conversions. They are currently developing a new cross bar for the LS conversion.

May not fit on cars using stock upper control arms. Tubular upper control arms are suggested.

Starting April 2010. Hotchkis have incorporated a adjustable top bar to increase adjustability and improve vehicle fitment due to manufacturing tolerance and condition of cars. The adjustable brace can also be installed on 68-74 Novas.

Features:

•Powder Coated, Anthracite Finish.
•Fabricated from 1.5" steel tubing, TIG welded to precision CNC bent brackets.
•CAD designed for superior fit and finish. Laser cut gussets maximize strength.
•Works with most suspension systems and engine installations.
•Easy, Bolt In Installation
•Additional pilot holes for Guldstrand modified a-arm mounts.

Benefits:

•Rigidly connects the shock towers, which dramatically reduces chassis, flex during hard cornering and acceleration.
•Triangulation brace ties control arms, shock towers and firewall together.
•Prevents changes in geometry, alignment and tire contact patch during high g-cornering.
•Improves driver control, handling and overall feel. Perfect final addition for any street machine, pro-touring car, autocross or road race Camaro.

Specifications

•Lbs. 23
•Dim. 20 x 5.5 x 41
ABOUT HOTCHKIS
For most automotive enthusiasts the name Hotchkis conjures up images of high performance machines hugging corners at high speeds. Hotchkis Sport Suspension is well regarded as one of the best suspension tuning companies in the world. Based in Santa Fe Springs, CA they have rewritten the rule book on suspension design with an assortment of innovative well-designed products that can absolutely transform a vehicles handling. With a proven record in the motorsports arena in all forms of competition from road racing to drag racing, Hotchkis has shown that their products are superior in both performance and durability. In addition they make all of their products locally right here in the USA. With two decades of automotive experience going into every design, Hotchkis truly knows what it takes to be number one.
FAQs
Q: What are subframe braces? Why buy them?
A: A subframe brace is a structural device that links the lower portion of your vehicle’s suspension to provide increased rigidity and reduced deflection to improve handling, vehicle control, and safety. Most modern rides rely on subframes to attach the suspension components to the chassis. These subframes can twist and deflect under harsh driving conditions causing sloppy and unpredictable handling characteristics. On the track this can mean valuable seconds, but on the street it can be a safety hazard as well. By firmly connecting and reinforcing your suspension components with a subframe brace you will have more predictable handling which will improve your confidence and help keep your vehicle both safe and fast as you drive down the road. In addition the added strength of a subframe brace can improve the lifespan of suspension components and the overall reliability of your ride.
