Belltech BT Torsion Bar Key - 1500HD / 2500HD / 3500HD 1in-3in Lift
Part #: 3928
$176.67
$159.00
For each
For each
Free Shipping! *to continental U.S. only
Fits On:
2011 Chevrolet Silverado 3500 HD, 2012 Chevrolet Silverado 3500 HD, 2013 Chevrolet Silverado 3500 HD, 2014 Chevrolet Silverado... See more
Description:
Belltech's BT Torsion Bar Keys are broached high-strength ductile iron castings E-coated for corrosion resistance, designed for torsion bar equipped IFS trucks and SUVs. The broaching angle is set to retain the factory spring rate and ride quality while allowing 1 to 3 inches of height adjustment.
Belltech's BT Torsion Bar Keys are broached high-strength ductile iron castings E-coated for corrosion resistance, designed for torsion bar equipped IFS trucks and SUVs. The broaching angle is set to retain the factory spring rate and ride quality while allowing 1 to 3 inches of height adjustment.
Q: What is a torsion key? Why buy them?
A: According to DJM Suspension, "To understand what a torsion bar key does we need to take a look at the whole torsion bar front end. First, a torsion bar is really a spring. It works just like a coil spring except it twists instead of compressing and expanding up and down. The word torsion means - to twist, and a torsion bar is a long bar lying parallel to the frame and the ground with both ends of the bar fixed. One in the frame and the other end is fixed in the lower control arm. As the lower control arm cycles up and down it twists the torsion bar because the other end is fixed in the frame and cannot spin. Torsion bar diameter and length will determine the rate of the bar, just as the wire diameter and the number of coils determine a coil springs rate. The lowering torsion bar key works by changing the indexing of the bar, rotating the hexagon shaped mount. When your truck is setting still, there is a certain amount of weight being held up by the torsion bar. This weight or load is a designed amount and dictates how high your truck sets. The lowering torsion bar key by rotating the index (hex shaped mount) causes that designed load to occur at a lower ride height, while everything else stays the same.
A: According to DJM Suspension, "To understand what a torsion bar key does we need to take a look at the whole torsion bar front end. First, a torsion bar is really a spring. It works just like a coil spring except it twists instead of compressing and expanding up and down. The word torsion means - to twist, and a torsion bar is a long bar lying parallel to the frame and the ground with both ends of the bar fixed. One in the frame and the other end is fixed in the lower control arm. As the lower control arm cycles up and down it twists the torsion bar because the other end is fixed in the frame and cannot spin. Torsion bar diameter and length will determine the rate of the bar, just as the wire diameter and the number of coils determine a coil springs rate. The lowering torsion bar key works by changing the indexing of the bar, rotating the hexagon shaped mount. When your truck is setting still, there is a certain amount of weight being held up by the torsion bar. This weight or load is a designed amount and dictates how high your truck sets. The lowering torsion bar key by rotating the index (hex shaped mount) causes that designed load to occur at a lower ride height, while everything else stays the same.
If you live in California, please note this item may be subject to a Proposition 65 warning. Click here to learn more.
When you click on links to various merchants on this site and make a purchase, this can result in this site earning a commission. Affiliate programs and affiliations include, but are not limited to, the eBay Partner Network.
